2℃~8℃/-10℃~-26℃ Combined Refrigerator And Freezer YCD-EL300
Description
Features
- Combination refrigerator freezer with upper 2°C ~ -8°C and
lower-10~-26℃
- Separate control of upper refrigeration chamber and lower
freezing chamber with separate compressors
- Direct cooling and electronic temperature control for fast
refrigeration and constant temperature
- Equipped with sheet metal refrigerated drawers and acrylic
plates
- Digital temperature display to control temperature precisely
and monitor operating status clearly
- Ensure safe sample storage with inter-room independent door
lock and independent external padlock
- The inner material with stainless steel and three layers
stainless steel clapboard
- Tube-type condenser and built-in type evaporator work well
to keep the temperature in the cabinet
- The lower freezing chamber is equipped with drawers and the
refrigeration chamber is equipped with steel wire shelves
- LED lighting in the cabinet of the combination refrigerator
freezer provides great visibility
- The combination refrigerator freezer is equipped with casters at the bottom for conveniently movement and placement
- Standard with Build-in USB datalogger for temperature data
recording
Specifications
- Capacity(L）
300,R:197,F:103
- Access port
- 2pcs. Ø 25 mm
- Ambient temperature
- 16~32℃
- Cabinet type
- Upright
- Casters
- 4 (2 casters with brake)
- Climate class
- N
- Compressor
- 2pcs
- Controller
- Microprocessor
- Cooling method
- R: Forced air cooling, F:Direct cooling
- Cooling performance
- R:5, F:-26
- Defrost mode
- R:Automatic, F:Manual
- Display
- Digital display
- Door lock
- Yes
- External material
- PCM
- External size(W*D*H)mm
- 700*640*1876
- Inner material
- Sprayed aluminum plate
- Insulation thickness(mm)
- B:50(R), 100(F)
- Internal size(W*D*H)mm
- R:600*510*657,F:500*460*535
- Model
- YCD-EL300
- NW/GW(Kgs)
- 95/106
- Package size(W*D*H)mm
- 760*720*1935
- Refrigerant
- R600a
- Shelves
- R:3(coated steel wired shelf),F:3(ABS)
- System
- Sensor failure, Door ajar
- Temperature
- High/Low temperature
- Temperature range
- R:2～8, F:-10～-26
