-86℃ Ultra-low Temperature Freezer (DW-HL50)
Description
Features Applied high-quality CFC free mixture refrigerant and Secop (Danfoss) compressor
Perfectly reduce noise and improve the cooling temperature performance to -86℃ stably
Equipped with international famous of Germany EBM fan electromotor
Power supply: 220V /50Hz 1 phase, can be changed as 220V 60HZ or 110V 60HZ.
Certificate: ISO9001, ISO14001,ISO13485.(CE,ETL will be finished in 2019.5)
Optional: RS485 remote contact, storage racks/boxes, CO2 back up system, vacuum isolated panel
Specifications
- Access Test Port
1 as standard, 2 or 3 is optional, diameter 25mm
- Cabinet Type
Upright
- Capacity (Effective)
50L
- Casters
4 units
- Compressor
1pcs
- Compressor Brand
(Secop) Danfoss brand, hermetic
- Cooling
Direct cooling
- Dimensions External (W*D*H,mm)
953W*700D*757H (mm)
- Dimensions Internal (W*D*H,mm)
430W*305D*425H (mm)
- Door Lock
1
- Evaporate
- D-form copper tube
- Fan Motor
EBM
- Inner doors
1pc
- Insulation
VIP Plus vacuum insulation panel
- Inventory Boxes
Inventory2" boxes: 42pcs boxes
- Material (External)
- Steel plates with spraying
- Material (Interior)
Galvanized steel sheet
- Model
DW-HL50
- Power (Input)
700W
- Power Consumption (kWh/24 hours)
8
- Rated Current (A)
4.5
- Refrigerant
CFC-Free Mixture gas
- Shelves
1pcs, made of stainless steel
- Status Alarm conditions
Visual & Audio
High and low temperature alarm, power failure alarm, low battery alarm, door ajar alarm, high air temperature alarm, communication failure alarm- Temp.Range(°C)
-10C ~ -86℃
- Temperature (Ambient)
16℃ ~ 32℃
- Temperature Record
Built-in datalogger USB data transfer interface
- Vials
Vials (2ml): 4200 pcs
- Voltage
- 220V,50Hz / 110V,60Hz / 220V,60Hz
- Weight (Net/Gross)
102 (Kg)
